090 Series Water Proof Terminals
TERMINAL 2.2 F WP
TERMINAL 2.2 F WP
Tab Size: 2.30X0.60
TERMINAL 2.2 F WP
| Part Code | Tab Size | Cable Size (mm²) | Applicable Mating Terminal |
|---|---|---|---|
| PMTL-TLB-0207 | 2.30X0.60 | 0.50~1.25 | PMTL-TLB-0158 |
TERMINAL 2.2 F WP - SMALL
TERMINAL 2.2 F WP - SMALL
Tab Size: 2.30X0.60
TERMINAL 2.2 F WP - SMALL
| Part Code | Tab Size | Cable Size (mm²) | Applicable Mating Terminal |
|---|---|---|---|
| PMTL-TLB-0221 | 2.30X0.60 | 0.30~0.50 | PMTL-TLB-0158 |
TERMINAL 2.2 F WP LOCK
TERMINAL 2.2 F WP LOCK
Tab Size: 2.30X0.60
TERMINAL 2.2 F WP LOCK
| Part Code | Tab Size | Cable Size (mm²) | Applicable Mating Terminal |
|---|---|---|---|
| PMTL-TLB-0113 | 2.30X0.60 | 0.50~1.25 | PMTL-TLB-0158 |
TERMINAL 2.2 M WP
TERMINAL 2.2 M WP
Tab Size: 2.30X0.60
TERMINAL 2.2 M WP
| Part Code | Tab Size | Cable Size (mm²) | Applicable Mating Terminal |
|---|---|---|---|
| PMTL-TLB-0158 | 2.30X0.60 | 0.50~1.25 | PMTL-TLB-0207 |
TERMINAL 2.2 M WP BIG
TERMINAL 2.2 M WP BIG
Tab Size: 2.30X0.60
TERMINAL 2.2 M WP BIG
| Part Code | Tab Size | Cable Size (mm²) | Applicable Mating Terminal |
|---|---|---|---|
| PMTL-TLB-0224 | 2.30X0.60 | 0.50~1.25 | NA |
TERMINAL 2.3 FRS PLATED
TERMINAL 2.3 FRS PLATED
Tab Size: 2.30X0.60
TERMINAL 2.3 FRS PLATED
| Part Code | Tab Size | Cable Size (mm²) | Applicable Mating Terminal |
|---|---|---|---|
| PMTL-TLB-0258 | 2.30X0.60 | 0.30~0.75 | NA |
